Key features/benefits
Lift Check Valve, Class 800–2500, SW/BW/screwed ends, full bore, cryogenic service, tested to BS standards, sizes 15–50 mm.
Class 800 / 1500 / 2500
Ends – SW/BW/ Screwed / Ext. Welded Flanges.
MOC-A105 A182F304/ A182F316 / F11 / F22 / LF2
Plug – 13%CR/SS304 / SS316 / Stellite Hard Faced.
Mfg. Std. BS 5352.
Test Std. – BS 6755 Part/1BS EN 12266 Part 1.
Optional Features Available.
Full Bore
Welded Cover
Other Trim Materials
NACE as per MR-01-75
Cryogenic Service
Size 15 mm to 50 mm
